Figure 2-9. Valve Module And Related Harnessing - ATI Corporation Level Best Grader Blade Operator's & Parts Manual

Figure 2-9.
Item Part No.
1 000-200-500
2 000-155-020
3 000-150-080
4 000-158-048
5 000-200-514
6 000-166-794
7 000-150-395
8 000-158-219
9 316-001-231
10 000-150-046
11 000-158-048
12
AR - As Required NSS - Not Serviced Separately
PARTS ILLUSTRATIONS
Valve Module and Related Harnessing
Qty
1 Module, Valve Control
2 Washer, Flat, 1/4"
2 Bolt, Socket Head, 1/4"-20UNC x 2-1/2" Long
2 Nut, Serrated Flange, 1/4"-20UNC
1 Harness, Grade Blade
1 Valve Assembly, Hydraulic, MVB10
8 Screw, Hex Head, #8-32UNC x 3/4" Long
8 Nut, Hex, Nylon Lock, #8-32UNC
1 Plate, Cover, Brace, Bulkhead, Mount
2 Bolt, Serrated Flange, 1/4"-20UNC x 1/2" Long
2 Nut, Serrated Flange, 1/4"-20UNC
1 Harness, Loader (Machine Specific) Refer to
ASN - After Serial No. BSN - Before Serial No.
Description
2.21
page 1.6
LP - Local Purchase
