ATI Corporation Level Best Grader Blade Operator's & Parts Manual page 47

Figure 2-8.
Item Part No.
1 000--166-793
2 000-161-168
3 000-161-204
4 000-150-078
5 000-158-233
6 000-166-697
7 000-166-807
8 000-166-808
9 000-166-864
10 000-166-863
11 000-150-097
000-166-837
AR - As Required NSS - Not Serviced Separately
PARTS ILLUSTRATIONS
Side Shift Cylinders, Hydraulics & Related Parts
Qty
1 Cylinder Assembly, Side Shift, 2-1/2" Bore x 26" Stroke, 3000 PSI
1 Pin, Link, 1" Dia. x 4-5/8" Long, w/Tab
1 Pin, Link, 1" Dia. x 3-3/8" Long, w/Tab
2 Bolt, Serrated Flange, 5/16"-18UNC x 1" Long
2 Nut, Flange, Nylon Lock, 5/16"-18UNC
2 Fitting, Elbow, 90°, 6OFS x 6MB
1 Hose, 3/8" Dia x 122" Long, 6FFORX x 6FFORX90
1 Hose, 3/8" Dia x 130" Long, 6FFORX x 6FFORX90L
3 Clamp, Hose Set, 5/8" Dia.
3 Plate, Top Hose Set
3 Bolt, Hex Head, 5/16"-18UNC x 2-1/4" Long
1 Kit, Cylinder Repair
BH-Bulkhead
MP-Male Pipe
FP-Female Pipe
FPX-Female Pipe Swivel
FFX- Female O-Ring Flat Face Swivel
MB-Male O-Ring Boss
FB-Female O-Ring Boss
MJ-Male JIC
FJ-Female JIC
FJX-Female JIC Swivel
OFS-O-Ring Face Seal
OFSBH-O-Ring Face Seal Bulkhead
ASN - After Serial No. BSN - Before Serial No.
Description
2.19
LP - Local Purchase
