ATI Corporation Level Best Grader Blade Operator's & Parts Manual page 45

Figure 2-7.
Item Part No.
1 000-166-791
2 000-161-211
3 000-150-097
4 000-158-066
5 000-161-192
6 000-150-077
7 000-158-223
8 000-166-697
9 000-166-857
10 000-166-802
11 000-166-858
12 000-166-809
13 000-166-695
14 NSS
15 000-155-093
16 000-166-805
17 000-166-806
18 000-166-864
19 000-166-863
20 000-150-097
000-166-835
AR - As Required NSS - Not Serviced Separately
PARTS ILLUSTRATIONS
Angle Cylinders, Hydraulics & Related Parts
Qty
2 Cylinder Assembly, Angle, 3" Bore x 19" Stroke, 3000 PSI
2 Pin, Link, 1-1/4" Dia x 4-5/8" Long
2 Bolt, Hex Head, 5/16"-18UNC x 2-1/4" Long
2 Nut, Hex, Nylon Lock, 5/16"-18UNC
2 Pin, Link, 1-1/4" Dia. x 2-5/8" Long, w/Tab
2 Bolt, Hex Head, 5/16"-18UNC x 1" Long
2 Nut, Flange, Nylon Lock, 5/16"-18UNC
4 Fitting, Elbow, 90°, 6OFS x 6MB
1 Hose, 3/8" Dia x 29" Long, 6FFORX x 6FFORX90, 270 Orientation
1 Hose, 3/8" Dia x 33" Long, 6FFORX x 6FFORX90L
1 Hose, 3/8" Dia x 33" Long, 6FFORX x 6FFORX90
1 Hose, 3/8" Dia x 36" Long, 6FFORX x 6FFORX90L, 130 Orientation
2 Fitting, Tee, Bulkhead Branch, 6OFS x 6OFS x 6OFSBH, Includes Item 14
2 Nut, Hex, Lock
2 Washer, Lock, 3/4"
1 Hose, 3/8" Dia x 42" Long, 6FFORX45 x 6FFORX90L, 270 Orientation
1 Hose, 3/8" Dia x 39" Long, 6FFORX45 x 6FFORX90, 270 Orientation
3 Clamp, Hose Set, 5/8" Dia.
3 Plate, Top Hose Set
3 Bolt, Hex Head, 5/16"-18UNC x 2-1/4" Long
1 Kit, Cylinder Repair
BH-Bulkhead
MP-Male Pipe
FP-Female Pipe
FPX-Female Pipe Swivel
FFX- Female O-Ring Flat Face Swivel
MB-Male O-Ring Boss
FB-Female O-Ring Boss
MJ-Male JIC
FJ-Female JIC
FJX-Female JIC Swivel
OFS-O-Ring Face Seal
OFSBH-O-Ring Face Seal Bulkhead
ASN - After Serial No. BSN - Before Serial No.
Description
2.17
LP - Local Purchase
