ATI Corporation Level Best Grader Blade Operator's & Parts Manual page 63

Figure 2-16. Topcon 3DMC W/Display on Attachment
Item Part No.
000-201-288
1 316-001-710
2 000-150-409
3 316-001-713
4 000-150-082
5 000-155-030
6 000-158-223
7 001-001-162
8 NSS
9 NSS
10 NSS
11 001-001-072
12 000-155-034
13 000-150-131
14 000-150-405
15 316-001-730
16 000-155-020
17 000-150-053
18 000-158-050
19 000-200-436
AR - As Required NSS - Not Serviced Separately
PARTS ILLUSTRATIONS
Qty
1 Kit, Topcon 3DMC W/ Screen on Attachment, Includes Items 1 thru 19
1 Plate
4 Bolt, Flange, Gr. 10.9, M8-1.25 x 16mm
1 Bracket, Topcon, Screen Mount
2 Bolt, Hex Head, 5/16"-18UNC x 1-1/4" Long
2 Washer, Flat, 5/16" SAE
2 Nut, Serrated Flange, Nylon Lock, 5/16"-18UNC
1 Jaw, Mounting Bracket, Control Panel, Topcon, Includes Items 8 thru 10
1 Knob
1 Disc
2 Screw
1 Stand Off
2 Washer, Lock, 3/8"
2 Bolt, Hex Head, 3/8"-16UNC x 1-1/2" Long
1 Bolt, Shoulder, 3/8" Dia. x 2" Shoulder x 5/16"-18UNC
1 Bracket, Slope
6 Washer, Flat, 1/4"
3 Bolt, Hex Head, 1/4"-20UNC x 1-3/4" Long
3 Nut, Hex, Nylon Lock, 1/4"-20UNC
1 Harness, Breakout A, Topcon 3D-MC, 5' Long
ASN - After Serial No. BSN - Before Serial No.
Description
2.35
LP - Local Purchase
