ATI Corporation Level Best Grader Blade Operator's & Parts Manual page 51

Figure 2-10. Joystick, Harness & Related Parts
Item Part No.
1 001-001-168
2 000-200-528
3 NSS
4 NSS
5 NSS
6 001-001-129
7 000-155-021
8 000-150-045
9 000-200-527
10 000-200-513
11
AR - As Required NSS - Not Serviced Separately
PARTS ILLUSTRATIONS
Qty
1 Bracket, Joystick
1 Joystick Assembly, Includes Items 3 thru 5
4 Bolt, Flange Head Socket
4 Washer, Lock
4 Nut, Hex
1 Cup, Vacuum
1 Washer, Lock, 1/4"
1 Bolt, Hex Head, 1/4"-20UNC x 1/2" Long
1 Harness, Extension, 4 Pin
1 Harness Assembly
1 Harness, Loader (Machine Specific) Refer to
ASN - After Serial No. BSN - Before Serial No.
Description
2.23
page 1.6
LP - Local Purchase
