ATI Corporation Level Best Grader Blade Operator's & Parts Manual page 55

Item Part No.
1 001-001-165
2 000-200-510
3 000-158-220
4 001-001-129
5 000-155-021
6 000-150-045
7 000-200-527
8 000-200-513
9
AR - As Required NSS - Not Serviced Separately
PARTS ILLUSTRATIONS
Figure 2-12. HMR, Harness & Related Parts
Qty
1 Bracket, HMR
1 HMR Assembly, Includes Items 3
3 Nut, Hex, Nylon Lock, M6
1 Cup, Vacuum
1 Washer, Lock, 1/4"
1 Bolt, Hex Head, 1/4"-20UNC x 1/2" Long
1 Harness, Extension, 4 Pin
1 Harness Assembly
1 Harness, Loader (Machine Specific) Refer to
ASN - After Serial No. BSN - Before Serial No.
Description
2.27
page 1.6
LP - Local Purchase
