SPECIFICATIONS AND MAINTENANCE

SPECIFICATIONS

GB-108 Specifications
Operating Weight
Width
Width Fully Angled
Length
Height
Blade Height
Maximum Blade Lift
Maximum Blade Cut
Hydraulic Blade Side Shift
(Left or Right)
Moldboard Angle (Left or Right)
Cutting Edge Size
GB-108 Hydraulic Valve
Valve Type
Minimal Flow Rate
Maximum Flow Rate
Maximum Hydraulic Pressure
2,620 lbs. (1,188kg)
108.0" (2.74m)
97.5" (2.48m)
99.9" (2.54m)
60.0" (1.52m)
16.9" (0.43m)
7.3" (0.19m)
7.7" (0.20m)
+/-13" (+/- 0.33m)
+/- 30°
5/8" x 6" Bolt-on, Reversible Double-Bevel Curved
4-Spool Proportional
12 GPM (45.4 LPM)
28 GPM (106 LPM)
4060 psi (280 bar)
1.14
