ATI Corporation Level Best Grader Blade Operator's & Parts Manual page 33

Figure 2-1.
Item Part No.
1 316-001-200
2 001-001-083
3 000-150-074
4 000-158-223
5 316-001-530
6 000-155-020
7 000-150-410
8 000-161-166
9 316-001-500
10 316-001-555
11 000-166-149
12 000-150-382
13 316-001-540
14 316-001-572
15 316-001-562
16 316-001-564
17 316-001-566
18 316-001-544
19 316-001-568
20 316-001-570
21 316-001-546
22 316-001-560
23 316-001-542
24 316-001-541
25 316-001-548
26 000-155-075
27 000-150-403
28 000-155-077
29 000-158-197
30 316-001-260
31 000-150-385
32 000-158-215
AR - As Required NSS - Not Serviced Separately
PARTS ILLUSTRATIONS
Main Frame, A-Frame and Related Parts
Qty
1 Frame, Main, Grade Blade
1 Canister, Operators Manual
3 Bolt, Serrated Flange, 5/16"-18UNC x 3/4" Long
6 Nut, Flange, Nylon Lock, 5/16"-18UNC
1 Plate, Support, Hydraulic Hose, Bolt-On, Front
4 Washer, Flat, 1/4" SAE
7 Bolt, Serrated Flange, 5/16"-18UNC x 1-1/4" Long
1 Pin, Pivot, 1-1/2" Dia. x 8" Long w/Tab
1 A-Frame, Grader Blade
1 Set Cap, Half, Pivot Ball Receiver, Includes Item 11
2 Fitting, Grease, Straight, 1/4"-28UNF
6 Bolt, Hex Head, Gr. 8, 5/8"-18UNF x 3" Long, (204 ft-lbs)
1 Wear Ring, A-Frame
AR Shim, 20 Ga, Back, A-Frame
2 Shim, 16 Ga, Back, A-Frame
1 Shim, 1/4", Back, A-Frame
1 Shim, 3/8", Back, A-Frame
1 Wear Pad, Back, A-Frame
1 Plate, Cap, Back, A-Frame, 3/8"
AR Shim, 20 Ga, Front, A-Frame
2 Shim, 16 Ga, Front, A-Frame
1 Shim, 1/4", Front, A-Frame
1 Shim, 3/8", Front, A-Frame
1 Wear Pad, Front, A-Frame
1 Plate, Cap, Front, A-Frame, 3/8"
8 Washer, Flat, 5/8" SAE
4 Bolt, Hex Head, Gr. 8, 5/8"-18UNF x 3-1/4" Long
4 Washer, Lock, 5/8"
4 Nut, Hex, 5/8"-18UNF
1 Arm, Pan, Hardrod
2 Bolt, Hex Head, Gr. 8, 1-1/8"-12UNF x 4" Long
2 Nut, Hex, Nylon Lock, 1-1/8"-12UNF
ASN - After Serial No. BSN - Before Serial No.
Description
2.5
LP - Local Purchase
