PARTS ILLUSTRATIONS
Figure 2-17. Topcon 3DMC W/Display in Cab
Mainfall/Junction Box
2
1
MC-R3 Controller
11
Main Frame
Machine Harness
Rotation Sensor
6
3
4
A-Frame
5
Carriage
Moldboard
Slope Sensor
Loader Connection
8
9
8
10
7
2.36
