ATI Corporation Level Best Grader Blade Operator's & Parts Manual page 57

Item Part No.
1 315-101-700
2 000-150-375
000-150-376
3 000-158-111
4 001-001-053
5 001-001-146
6 316-001-733
7 316-001-700
8 000-150-256
9 000-158-142
10 3126-001-723
11 316-001-727
12 001-001-077
13 LP
14 001-001-179
15 000-155-032
16 000-158-084
AR - As Required NSS - Not Serviced Separately
PARTS ILLUSTRATIONS
Figure 2-13. Optional Equipment
Qty
2 Mount, Mast Pole
8 Bolt, Serrated Flange, 1/2"-13UNC x 1-1/4" Long
8 Bolt, Serrated Flange, 1/2"-13UNC x 2" Long, used with Item 6
8 Nut, Serrated Flange, 1/2"-13UNC
4 Handle, Tee
2 Pole, Mast, Black, 1-3/4" Dia x 7' Long
2 Bracket, Sonic
2 Plate, End, Moldboard
6 Bolt, Carriage, 5/8"-11UNC x 1-1/2" Long
6 Nut, Serrated Flange, 5/8"-11UNC
1 Kit, Mirror, Includes Items 11 thru 16
1 Bracket, Tube, Bent, Mirror
2 Clamp Assembly, Mirror Bracket, Included Item 13
4 Bolt, Hex Head, 1/4"-20UNC x 1-1/2" Long
2 Mirror, Safety, 8" x 12", W/12" Radius
2 Washer, Flat, 3/8" SAE
2 Nut, Hex, Nylon Lock, 3/8"-16UNC
ASN - After Serial No. BSN - Before Serial No.
Description
2.29
LP - Local Purchase
