Item
Part No.
1
000-166-792
2
000-176-268
3
316-001-295
4
316-001-277
5
000-150-393
6
000-158-217
7
000-155-013
8
000-176-171
9
000-155-004
10
000-150-396
11
000-150-383
12
000-158-215
000-166-836
AR - As Required
NSS - Not Serviced Separately
PARTS ILLUSTRATIONS
Figure 2-5.
Lift Cylinders & Related Parts
Qty
2
Cylinder Assembly, Lift, 2-1/4" Bore x 16-3/4" Stroke, 3,000 PSI
4
Bushing, Flange, Cylinder Yoke
2
Yoke Weldment, Lift Cylinder
4
Spacer, Trunion, Lift Cylinder
4
Bolt, Serrated Flange, 3/8"-16UNC x 3" Long
4
Nut, Serrated Flange, 3/8"-16UNC,
4
Washer, 2-3/4" OD x 1-1/2" ID x 10 Gauge
4
Bushing, 1-3/4" OD x 1-1/2" ID x 1-1/2" Long
2
Washer, Flat, 2-1/4" OD x 17/32" ID x 1/4" Thick
2
Bolt, Serrated Flange, 1/2"-13UNC x 1" Long,
2
Bolt, Hex Head, Gr. 8, 1-1/8"-12UNF x 4-1/2" Long
2
Nut, Hex, Nylon Lock, 1-1/8"-12UNF
1
Kit, Cylinder Repair
ASN - After Serial No. BSN - Before Serial No.
Description
(26 ft-lbs blue Loctite)
2.13
(57 ft-lbs blue Loctite)
LP - Local Purchase
