ATI Corporation Level Best Grader Blade Operator's & Parts Manual page 39

Item Part No.
1 000-166-868
2 000-166-824
3 000-166-694
4 000-166-685
5 NSS
6 000-166-843
7 000-166-844
8 000-150-119
9 000-150-074
10 000-166-810
11 000-166-862
12 000-166-861
13 000-150-104
14 000-166-859
15 000-166-860
AR - As Required NSS - Not Serviced Separately
PARTS ILLUSTRATIONS
Figure 2-4. Valve Assembly & Related Parts
Qty
1 Valve Assembly, Hydraulic, MVB10, Includes Items 2 thru 7
1 Valve, Check, 12OFS x 12MB, (DO NOT REMOVE FROM ITEM 1)
1 Fitting, Adapter, 12OFS x 12MB
8 Fitting, Adapter, 6OFS x 6MB
4 Stem
8 Coil
8 Valve, Counter Balance
1 Bolt. Serrated Flange, 3/8"-16UNC x 3/4" Long
2 Bolt, Serrated Flange, 5/16"-18UNC x 3/4" Long
2 Hose, 5/8" Dia x 80" Long, 10MORB x 12FFORX90
1 Clamp, Hose Set
1 Plate, Top Hose Clamp
2 Bolt, Hex Head, 5/16"-18UNC x 3-1/4" Long
1 Coupler, Quick Disconnect, Flat Face, Male (Tank Line)
1 Coupler, Quick Disconnect, Flat Face, Female (Pressure Line)
BH-Bulkhead
MP-Male Pipe
FP-Female Pipe
FPX-Female Pipe Swivel
FFX- Female O-Ring Flat Face Swivel
MB-Male O-Ring Boss
FB-Female O-Ring Boss
MJ-Male JIC
FJ-Female JIC
FJX-Female JIC Swivel
OFS-O-Ring Face Seal
OFSBH-O-Ring Face Seal Bulkhead
ASN - After Serial No. BSN - Before Serial No.
Description
2.11
LP - Local Purchase
