Figure 2-11. Joystick, Harness & Related Parts (Rental)
Item Part No.
1 001-001-168
2 000-200-528
3 NSS
4 NSS
5 NSS
6 001-001-129
7 000-155-021
8 000-150-045
9 000-200-524
AR - As Required NSS - Not Serviced Separately
PARTS ILLUSTRATIONS
Qty
1 Bracket, Joystick
1 Joystick Assembly, Includes Items 3 thru 5
4 Bolt, Flange Head Socket
4 Washer, Lock
4 Nut, Hex
1 Cup, Vacuum
1 Washer, Lock, 1/4"
1 Bolt, Hex Head, 1/4"-20UNC x 1/2" Long
1 Harness Assembly
ASN - After Serial No. BSN - Before Serial No.
Description
2.25
LP - Local Purchase
