Figure 2-3.
Item Part No.
1 316-001-300
2 000-176-171
3 000-155-013
4 000-176-267
5 316-001-610
6 000-155-100
7 000-155-102
8 000-150-375
9 001-001-158
10 NSS
11 000-166-865
12 000-176-270
13 000-166-838
14 000-158-120
15 316-001-630
16 316-001-620
17 001-001-155
18 316-001-640
19 000-158-212
20 000-161-202
AR - As Required NSS - Not Serviced Separately
PARTS ILLUSTRATIONS
Wheel Frame, Caster Fork and Related Parts
Qty
1 Pivot, Axle Grader
2 Bushing, 1-3/4" OD x 1-1/2" ID x 1-1/2" Long
2 Washer, Flat, 2-3/4" OD x 1-1/2" ID x 10 Ga.
4 Bushing, 2.3705" OD X 2.008" ID
2 Fork, Caster
4 Bushing, Washer, 3-3/8" OD x 2.015" ID x 10 Gauge
2 Washer, Flat, 3-38" OD x .555" ID x 1/4" Thick
2 Bolt, Serrated Flange, 1/2"-13UNC x 1-1/4" Long,
2 Hub Assembly, Includes Items 10 thru 14
1 Hub, Wheel, Includes Item 11
1 Fitting, Grease, 65°
4 Bearing, Roller, Tapered, 1.3750" ID, 1.0520" Width
4 Seal, 2.718 " OD x 1.750 " ID x .359 " Thick
10 Nut, Lug, Hex, 1/2"-20UNF
2 Spacer, Wheel Hub, Long
2 Spacer, Wheel Hub, Short
2 Wheel/Tire, Foam Filled , 23/8.50-12
2 Axle, Caster, 1-3/8" -12UNF x 13-1/2" Long
4 Nut, Castle, 1-3/8"-12UNF
4 Pin, Cotter, 1/4" Dia. x 3" Long
ASN - After Serial No. BSN - Before Serial No.
Description
2.9
(57 ft-lbs blue Loctite)
LP - Local Purchase
