Top view on the opened OM2000A+
Tetrode FU728F
Blower
Power Supply Board
Switch-ON Board
Output Pi-L Circuit
Tuning Capacitor
Front Subpanel
HV
transformer
3.2.
Power Supply
This Power amplifier uses one 3 KVA toroidal transformer. A soft start is provided using relays and
resistors (placed on the switch-ON board). The high voltage is made by combining 4 x 575V AC (total
8
