OM POWER OM2000A+ Manual page 24

Pressing MEAS displays this screen.
Type of supported TCVR and working
Instantaneous values
amplifier parameters are displayed.
frequency are visible on the display.
NOTE: You can FREEZE the screen
and/or allow constant monitoring.
Three different bar graphs can be defined
Type of supported TCVR and working
using BARG1, BARG2 or BARG3 buttons.
frequency are visible on the display.
Press BARG1.
AUTO LED is ON.
Green graph may show one of the user
Type of supported TCVR and working
selectable 8 monitored
Select the wanted parameter from the list frequency are visible on the display.
at the bottom of the screen and press
SAVE.
AUTO LED is ON.
NOTE: Follow these steps to populate
BARG2 and BARG3 as desired.
of the basic
AUTO LED is ON.
parameters.
24
