OM POWER OM2000A+ Manual page 16

.
BCD code (4 bits) is used for automatic antenna and BPF switching (see Antenna/BPF
connector on the Control panel (rear side of the PA). See section 7.9 for Control and ANT/BPF
connectors pin-out.
You selected IC7800 addr.6AH and 19200
Bd. Press SET to write to the memory,
Type of supported TCVR and
then press EXIT to go back to the
SETTINGS possibilities.
"SET OTHER ADDRESS" means that you frequency are visible on the
must add here a new type of ICOM TCVR
which is not defined in the table (its
address plus bitrate in Bd) to allow
communications with it.
AUTO LED is ON.
Press ANTENNA SETTINGS. First select
ANTENNA SWITCH
Standard). Use left or right arrows. If you
Type of supported TCVR and
select some switch, 10 ports for different
antennas displays.
frequency are visible on the
antennas are allowed in every band
(green squares). To disable some square
select port (up/down), touch SET for
antenna name and then select band
(left/right). Press SET. AUTO LED is ON.
Four types of antennas for four different
bands were disabled.
Type of supported TCVR and
Black square
combination.
frequency are visible on the
Press EXIT to go back to SETTINGS
menu
AUTO LED is ON.
working
display.
(No switch,
working
Generally all of
display.
working
means disabled
display.
16
