9 Technical specifications

(Manual)
Dimensions (WxHxD)
Fastening
Material
Colours
Weather protection
Temperature range (operation)
Battery type
Battery lifetime (SI)
Signalisation
Network capability
Frequency range; max. transmission
power RFID (~13,56 MHz)
Frequency range; max. transmission
power (~868 MHz)
Frequency range; max. transmission
power BLE
Geographical restrictions within the
EU
9. Technical specifications
Reader: 41.3×75.3×20.0 mm, motor
block: 59×75×21 mm, bolt: 15×20×3
mm
Standard locker lock flange (Ø19×16
mm) with double D punch
Glass-fibre reinforced plastic
Anthracite
IP40
0 °C to +65 °C
2x AA cell 1.5 V (alkaline)
SVCN: Up to 50,000 openings or 40
years standby (limited by the life of
the battery itself).
- Audible signal (buzzer) and/or
visual signal (LED – green/red)
Yes (integrated LockNode can be
ordered and retrofitted)
13.560060 MHz - 13.560719 MHz;
-14 dBμA/m (10 m distance)
868.000 MHz - 868.600 MHz; <25
mW ERP (depending on equip-
ment)
2360 MHz - 2500 MHz; 4 mW
No
