  • Page 1 SI SmartLocker AX Manual 23.08.2021...

  • Page 2: Table Of Contents

    Contents SI SmartLocker AX (Manual) 2 / 36 Contents Intended use .............................. 3 General safety instructions........................ 4 Scope of delivery............................ 7 Initial operation............................ 8 Programming .............................. 8 Measurement and calculation ........................ 8 Installation................................ 9 Operation.............................. 22 Battery change............................ 23 Emergency power supply........................... 25 Signalisation .............................  26 Disassembly...............................  27 Technical specifications ........................

  • Page 3: Intended Use

    1. Intended use SI SmartLocker AX (Manual) 3 / 36 1 Intended use SmartLocker AX allows you to manage and control your cabinets and lockers conveniently and efficiently. You can programme directly from your workstation or carry out remote opening via the optional radio link.

  • Page 4: General Safety Instructions

    2. General safety instructions SI SmartLocker AX (Manual) 4 / 36 2 General safety instructions Signal word (ANSI Possible immediate effects of non-compliance Z535.6) DANGER Death or serious injury (likely) WARNING Death or serious injury (possible, but unlikely) CAUTION Minor injury...
  • Page 5 2. General safety instructions SI SmartLocker AX (Manual) 5 / 36 Damage resulting from liquids This product contains electronic components that may be damaged by liquids of any kind. Keep liquids away from the electronics.  Damage resulting from aggressive cleaning agents The surface of this product may be damaged as a result of the use of unsuitable cleaning agents.
  • Page 6 2. General safety instructions SI SmartLocker AX (Manual) 6 / 36 Qualifications required The installation and commissioning requires specialized knowledge. Only trained personnel may install and commission the product.  Incorrect installation SimonsVoss Technologies GmbH accepts no liability for damage caused to doors or compon- ents due to incorrect fitting or installation.

  • Page 7: Scope Of Delivery

    3. Scope of delivery SI SmartLocker AX (Manual) 7 / 36 3 Scope of delivery Reader  Motor block  Connection socket  3 adapter plates (can be reordered: (LL.PLATE5)  Adapter plate with forced guide (can be reordered: LL.PLATEVAR) ...

  • Page 8: Initial Operation

    4. Initial operation SI SmartLocker AX (Manual) 8 / 36 4 Initial operation 4.1 Programming (For programming for SmartIntego, see Step-by-Step Guide). 4.2 Measurement and calculation 1. Measure the distance between the inside of the door and the dead-bolt stop (A), e.g. with the depth rod of a caliper gauge.

  • Page 9: Installation

    4. Initial operation SI SmartLocker AX (Manual) 9 / 36 Adapter plate P Inner side of door up to dead-bolt Dead-bolt fix- stop (A) ture R (LL.PLATE5) 17.35 mm to 18.85 mm 2 × 5 mm 2 (9.1 mm) 18.95 mm to 20.45 mm 2 × 5 mm 1 (10.4 mm)
  • Page 10 4. Initial operation SI SmartLocker AX (Manual) 10 / 36 Slotted screwdriver (if the dead-bolt block needs to be replaced)  2.5 mm hex wrench  TX10 screwdriver  ü SmartLocker AX closed ex factory (= dead-bolt extended), programme Programming [  8]...
  • Page 11 4. Initial operation SI SmartLocker AX (Manual) 11 / 36 3. Using needle-nosed pliers, disconnect the plug of the cable below the circuit board. 4. Disassemble the reader and engine block. 5. Insert the socket into the D-hole (mount for nut pointing towards the edge of the door).
  • Page 12 4. Initial operation SI SmartLocker AX (Manual) 12 / 36 7. Slide the forced guide out until it rests against the inner edge of the door. 8. Continue to press the forced guide against the inner edge and screw the screws tight with approx.
  • Page 13 4. Initial operation SI SmartLocker AX (Manual) 13 / 36 10. If necessary, lever the dead-bolt block out of the engine block using a slotted screwdriver. 11. If necessary, insert another dead-bolt block into the engine block. 12. Hook the screw into the holder and hold it in place.
  • Page 14 4. Initial operation SI SmartLocker AX (Manual) 14 / 36 13. Fix the screw through the dead-bolt side hole on the back with the plastic mounting tool. 14. If necessary, plug in the flange extensions on the engine block. 15. Hold the plastic mounting tool with one finger and place the engine block on the adapter plate or through the D-hole bushing.
  • Page 15 4. Initial operation SI SmartLocker AX (Manual) 15 / 36 17. Place the nut on the screw and carefully tighten the nut with the as- sembly tool already installed until it is seated in the hexagonal mount.
  • Page 16 4. Initial operation SI SmartLocker AX (Manual) 16 / 36 18. Tighten the nut with 1 Nm (2.5 mm hex wrench). 19. Insert the clamping element and the plastic countersunk screw into the D-hole bushing from the front.
  • Page 17 4. Initial operation SI SmartLocker AX (Manual) 17 / 36 20.Screw the tensioner until it stops (TX10 key) without screwing through the screw. 21. Place the reader at an angle (approx. 45°).
  • Page 18 4. Initial operation SI SmartLocker AX (Manual) 18 / 36 22. Turn the reader clockwise straight (bayonet mount). 23. Route the cable past next to the area of the light guide. 24.Insert the plug into the socket with the lug facing the circuit board using the special tool.
  • Page 19 4. Initial operation SI SmartLocker AX (Manual) 19 / 36 25. Attach the light guide and press it firmly. Reader protected against twisting. 26.Store the excess cable in the gap next to the PCB. 27. Hook the lid on top.
  • Page 20 4. Initial operation SI SmartLocker AX (Manual) 20 / 36 28.Close the lid downwards. 29.Gently press the lid against the floor and unscrew the lower screw counterclockwise (0.9 mm hex wrench) until it is flush with the lid sur- face.
  • Page 21 4. Initial operation SI SmartLocker AX (Manual) 21 / 36 SmartLocker AX is completely assembled.

  • Page 22: Operation

    5. Operation SI SmartLocker AX (Manual) 22 / 36 5 Operation Present an ID medium to the SmartLocker AX.  SmartLocker AX signals reaction (see Signalisation [  26] SmartLocker AX reacts as configured.

  • Page 23: Battery Change

    6. Battery change SI SmartLocker AX (Manual) 23 / 36 6 Battery change ü SmartLocker's back accessible. Slot screwdriver available. ü 1. Put the slot screwdriver in the intended notch. 2. Turn the screwdriver as shown to lift the battery lid. Push the lid to the case's edge.
  • Page 24 6. Battery change SI SmartLocker AX (Manual) 24 / 36 4. Hook in the lid's long flap first, then hook in the the short flap. 5. Push the lid against the case and push it in the direction of the short flap until it snaps in.

  • Page 25: Emergency Power Supply

    6. Battery change SI SmartLocker AX (Manual) 25 / 36 NOTE Emergency supply if totally discharged If you ignore the battery warnings, the SmartLocker AX may fail to open. If this happens the battery compartment is no longer accessible. You may connect an emergency power supply for changing the batteries.

  • Page 26: Signalisation

    7. Signalisation SI SmartLocker AX (Manual) 26 / 36 7 Signalisation Signal Explanation 1× Beeping Lock locked. 2× Beeping und Flashing (green) Lock unlocked. 3 × Beeping Reset/Battery change. 3× Beeping and Flashing Motor unit and reader connected. 4 × Beeping and Flashing LockNode connected.

  • Page 27: Disassembly

    8. Disassembly SI SmartLocker AX (Manual) 27 / 36 8 Disassembly Disassembly is reversed to assembly. Carefully press the light guide down to make it easier to remove the cover.

  • Page 28: Technical Specifications

    9. Technical specifications SI SmartLocker AX (Manual) 28 / 36 9 Technical specifications Reader: 41.3×75.3×20.0 mm, motor Dimensions (WxHxD) block: 59×75×21 mm, bolt: 15×20×3 Standard locker lock flange (Ø19×16 Fastening mm) with double D punch Material Glass-fibre reinforced plastic Colours...

  • Page 29: Dimensional Drawings

    9. Technical specifications SI SmartLocker AX (Manual) 29 / 36 9.1 Dimensional drawings...

  • Page 30: Drawings Of Installation Situations

    9. Technical specifications SI SmartLocker AX (Manual) 30 / 36 To assess compatibility, please note the following information: Wooden doors The door must be between 10 mm and 25 mm thick.  With metal spindles, at least two adapter plates must therefore be used for standard material thicknesses (1 mm to 2 mm).
  • Page 31 9. Technical specifications SI SmartLocker AX (Manual) 31 / 36 Metal locker 1 min. 15.9 mm max. 30.4 mm min. 10 mm max. 25 mm Locker frame Bolt Motor block Door with hole and hinge Adapter plate 5 mm (variable)
  • Page 32 9. Technical specifications SI SmartLocker AX (Manual) 32 / 36 Metal locker 2 min. 15.9 mm max. 30.4 mm min. 10 mm max. 25 mm Locker frame Bolt Motor block Door with hole and hinge Adapter plate 5 mm (variable)
  • Page 33 9. Technical specifications SI SmartLocker AX (Manual) 33 / 36 Wooden locker min. 10 mm max. 30.4 mm min. 5.9 mm max. 25 mm Door frame with stop bracket Bolt Motor block Door with hole and hinge Adapter plate 5 mm (variable)

  • Page 34: Eu/Uk Declaration Of Conformity

    10. EU/UK Declaration of conformity SI SmartLocker AX (Manual) 34 / 36 10 EU/UK Declaration of conformity The company SimonsVoss Technologies GmbH hereby declares that article SV-LL.*; SI-LL.* complies with the following guidelines: 2014/53/EU "Radio equipment"  as well as the corresponding UK statutory 2017 No. 1206 "Radio equipment"...

  • Page 35: Help And Other Information

    11. Help and other information SI SmartLocker AX (Manual) 35 / 36 11 Help and other information Information material/documents You will find detailed information on operation and configuration and other documents on the website: www.smartintego.com/int/home/infocenter/documentation Declarations of conformity You will find declarations of conformity and other certificates on the website: www.simons-voss.com/en/certificates.html...
