SmartRelais 3 Leser
NOTE
A transponder's read range may be reduced due to interference in the
surrounding area.
Strong magnetic fields can shorten the read range. Aluminium struc-
tures may block communication between the transponder and reader.
You can enable the
software. This option reduces the B field reader range, reduces the
impact from possible sources of interference and can prevent a
transponder from overmodulating.

5.2 Use of cards

The card-to-reader range (read range) extends up to 1.5 cm.
Direct contact must be established between the card and reader once
the reader is mounted.

6 Technical specifications

Housing
Material
Colour
EN
Close-up range mode option in the LSM
ABS plastic, UV-stable
Same as RAL 9016 (traffic white)
6. Technical specifications
33 / 132
