SmartLocker AX

9 Technical specifications

(Manual)
Dimensions (WxHxD)
Fastening
Material
Colours
Weather protection
Temperature range (operation)
Battery type
Battery lifetime (3060)
Signalisation
Network capability
Reading technologies (3060)
Networking modes
Storable accesses (3060)
Time zone groups
Number of identification media that
can be managed per lock
Frequency range; max. transmission
power SRD (~25 kHz)
Frequency range; max. transmission
power RFID (~13,56 MHz)
Frequency range; max. transmission
power (~868 MHz)
9. Technical specifications
Reader: 41.3×75.3×20.0 mm, motor
block: 59×75×21 mm, bolt: 15×20×3
mm
Standard locker lock flange (Ø19×16
mm) with double D punch
Glass-fibre reinforced plastic
Anthracite
IP40
0 °C to +65 °C
2x AA cell 1.5 V (alkaline)
Up to 60,000 lock operations or up
to 5 years on standby (depending
on read technology and operating
mode)
- Audible signal (buzzer) and/or
visual signal (LED – green/red)
Yes (integrated LockNode can be
ordered and retrofitted)
Active (25 kHz), passive (MIFARE®
Classic and DESFire EV1, EV2, EV3,
hybrid (active and passive),
Bluetooth Low Energy (BLE) in pre-
paration
Online, virtual network and offline
(can be combined)
3,000
100+1 (G2)
Up to 64,000
25 kHz (fL>10 kHz, fH<40
kHz);-28.5 dBμA/m (10m distance)
13.560060 MHz - 13.560719 MHz;
-14 dBμA/m (10 m distance)
868.000 MHz - 868.600 MHz; <25
mW ERP (depending on equip-
ment)
