SmartIntego PadLock AX

6 Technical specifications

(Manual)
Dimensions (WxHxD)
Dimensions knob (Øxlength)
Shackle diameter
Shackle internal heigth
Material
Colours
Thumb-turn covers for reader
thumb-turn
Certifications
Weather protection
Temperature range (operation)
Battery type
Approved battery manufacturers
Battery lifetime
Signalisation
Network capability
Opening modes
Upgradeability
Frequency range; max. transmission
power RFID (~13,56 MHz)
Frequency range; max. transmission
power (~868 MHz)
6. Technical specifications
Basic body without knob/shackle:
70×51×25 mm (8 mm shackle) or
72.5×60×25 mm (11 mm shackle)
Ø 32 mm × 39.5 mm (electronic)
8mm / 11mm
For 8mm shackle: 25/60 mm or for
11 mm shackle: 50mm
Body/bracket: Stainless steel, active
knob: Stainless steel ring cap, pass-
ive/hybrid knob: Plastic cap
Stainless steel, brushed
Plastic cap (passive/hybrid), metal
ring cap (active), full metal cap
(active)
Class 3 (8 mm) or Class 4 (11 mm)
according to EN 12320
IP67
25 °C to +65 °C (according to DIN
EN 15684)
2x CR2450 3V (lithium)
Murata, Panasonic, Varta
Up to 12 years on standby or
100,000 activations
Audible signal (buzzer) and/or
visual signal (LED – green/red)
Yes (integrated LockNode can be
ordered and retrofitted)
Pulse flip-flop
Firmware upgradable via BLE
13.560006 MHz - 13.560780 MHz;
1.04 dBµA/m (3 m distance, de-
pending on equipment)
868.000 MHz - 868.600 MHz; <25
mW ERP (depending on equip-
ment)
