Operating menu

Output echo lost

Navigation
Description
Selection
Factory setting
Additional information

Value echo lost

Navigation
Prerequisite
Description
User entry
Factory setting
Additional information
6) Only visible if ' " Linearization type (→  135)" = "None"
142
"Safety settings" submenu
Navigation  Setup → Advanced setup → Safety settings
 Setup → Advanced setup → Safety settings → Output echo lost
Output signal in case of a lost echo.
• Last valid value
• Ramp at echo lost
• Value echo lost
• Alarm
Last valid value
Meaning of the options
• Last valid value
The last valid value is kept in the case of a lost echo.
6)
• Ramp at echo lost
In the case of a lost echo the output value is continously shifted towards 0% or 100%.
The slope of the ramp is defined in the Ramp at echo lost parameter (→  143).
6)
• Value echo lost
In the case of a lost echo the output assumes the value defined in the Value echo lost
parameter (→  142).
• Alarm
In the case of a lost echo the device generates an alarm; see the Failure mode parameter
(→  152)
 Setup → Advanced setup → Safety settings → Value echo lost
Output echo lost (→  142) = Value echo lost
Output value in case of a lost echo
0 to 200 000.0 %
0.0 %
Use the unit which has been defined for the measured value output:
• without linearization: Level unit (→  130)
• with linearization: Unit after linearization (→  136)
