Levelflex FMP53 HART
Additional information

Tube diameter

Navigation
Prerequisite
Description
User entry
Factory setting

Medium group

Navigation
Prerequisite
Description
Selection
Factory setting
Additional information
Endress+Hauser
• Depending on the probe some of the options mentioned above may not be available or
there may be additional options.
• For coax probes and probes with metallic center washer Tank type parameter
corresponds to the type of probe and cannot be changed.
 Setup → Tube diameter
Tank type (→  116) = Bypass / pipe
Specify diameter of bypass or stilling well.
0 to 9.999 m
0.0384 m
 Setup → Medium group
Medium type (→  127) = Liquid
Select medium group.
• Others
• Water based (DC >= 4)
Others
This parameter roughly specifies the dielectric constant (DC) of the medium. For a more
detailed definition of the DC use the Medium property parameter (→  127).
The Medium group parameter presets the Medium property parameter (→  127) as
follows:
Medium group
Others
Water based (DC >= 4)
The Medium property parameter can be changed at a later point of time. However,
when doing so, the Medium group parameter retains its value. Only the Medium
property parameter is relevant for the signal evaluation.
The measuring range may be reduced for small dielectric constants. For details refer
to the Technical Information (TI) of the respective device.
Medium property (→  127)
Unknown
DC 4 ... 7
Operating menu


117
