Levelflex FMP51, FMP52, FMP54 PROFIBUS PA

Output echo lost

Navigation
Description
Selection
Additional information

Value echo lost

Navigation
Prerequisite
Description
User entry
Additional information
12) Only visible if ' " Linearization type (→  163)" = "None"
Endress+Hauser
"Safety settings" submenu
Navigation  Setup → Advanced setup → Safety sett.
 Setup → Advanced setup → Safety sett. → Output echo lost
Output signal in case of a lost echo.
• Last valid value
• Ramp at echo lost
• Value echo lost
• Alarm
Meaning of the options
• Last valid value
The last valid value is kept in the case of a lost echo.
12)
• Ramp at echo lost
In the case of a lost echo the output value is continously shifted towards 0% or 100%.
The slope of the ramp is defined in the Ramp at echo lost parameter (→  172).
12)
• Value echo lost
In the case of a lost echo the output assumes the value defined in the Value echo lost
parameter (→  171).
• Alarm
In the case of a lost echo the device generates an alarm; see the Failure mode parameter
 Setup → Advanced setup → Safety sett. → Value echo lost
Output echo lost (→  171) = Value echo lost
Output value in case of a lost echo
0 to 200 000.0 %
Use the unit which has been defined for the measured value output:
• without linearization: Level unit (→  152)
• with linearization: Unit after linearization (→  164)
Operating menu


171
