Mounting
22
Additional conditions
• When mounting in the open, a weather protection cover (1) may be installed to protect
the device against extreme weather conditions.
• Do not mount the probe in the filling curtain (2).
When mounting the electronics housing into a recess (e.g. in a concrete ceiling),
observe a minimum distance of 100 mm (4 inch) between the cover of the terminal
compartment / electronics compartment and the wall. Otherwise the connection
compartment / electronics compartment is not accessible after installation.
