Device integration via the HART protocol
68
9
Device integration via the HART protocol
9.1

Overview of the Device Description files (DD)

HART
Manufacturer ID
Device type
HART specification
DD files
9.2

HART device variables and measuring values

On delivery the following measruing values are assigned to the HART device varaibles:
Device variables for level measurements
Device variable
Primary variable (PV)
Secondary variable (SV)
Tertiary variable (TV)
Quaternary variable (QV)
The allocation of the measuring values to the device variables can be changed in the
following submenu:
Expert → Communication → Output
0x11
0x1122
7.0
For information and files see:
www.endress.com
www.fieldcommgroup.org
Levelflex FMP53 HART
Measuring value
Level linearized
Unfiltered distance
Absolute echo amplitude
Relative echo amplitude
Endress+Hauser
