Operating menu
Present mapping
Navigation
Description
Mapping end point
Navigation
Prerequisite
Description
User entry
Factory setting
Additional information
Record map
Navigation
Prerequisite
Description
Selection
Factory setting
122
 Setup → Present mapping
Indicates up to which distance a mapping has already been recorded.
 Setup → Mapping end point
Confirm distance (→  121) = Manual map or Distance too small
Specify new end of the mapping.
0 to 200 000.0 m
0.1 m
This parameter defines up to which distance the new mapping is to be recorded. The
distance is measured from the reference point, i.e. from the lower edge of the mounting
flange or the threaded connection.
For reference purposes the Present mapping parameter (→  122) is displayed
together with this parameter. It indicates up to which distance a mapping has already
been recorded.
 Setup → Record map
Confirm distance (→  121) = Manual map or Distance too small
Start recording of the map.
• No
• Record map
• Delete map
No
