Type 2 - Directed DS4+ Installation Manual

Wiring diagram

Type 2

Refer to "Pre-installation and application warnings" on page 4 for important information, such as the description of each special note referenced in the diagram (
Diagnostic Connector OBDII
(connector side view)
F-CAN High: White, Pin 6
1
9
F-CAN Low: Black, Pin 14
Immobilizer Data:
Lt. Green, pin 21
Ignition:
Cut
Yellow, pin 17
Keyless Access
Control Unit
(Gray conn. right side
of steering column)
(White connectors right
13
(+) Starter: Lt. Green, pin 10
Push-to-Start: Lt. Blue, pin 7
1 2 3 4
19 20 21 22
8
16
Headlight Switch
1 2 3
(Black & White conn.
7 8 9
at headlight)
(-) Parking Lights:
Gray, pin 11
(+) 12V:
White, pin 1
1
(+) Ignition 1:
Blue, pin 4
4
3
(+) Ignition 2:
2
Red, pin 3
Power Control Unit
1
(+) Accessory:
Orange, pin 1
of steering column)
Power Control Unit
(Lt. Blue conn. right of column)
5 6 7 8 9 10 11 12 13 14 15 16 17
23 24 25 26 27 28 29 30 31 32 33 34 35
B-CAN High: B-CAN Low:
Pink, pin 16 Blue, pin 17
(-) Autolights, Pink, pin 9
(-) Autolight Off Output: Brown/White: 6
(-) Parking Lights Output: Lt. Blue/Black: 10
4 5 6
10 11 12
Siren
Hood Pin
Ignition Interrupt (veh. side): Blue/White: 1
Ignition Interrupt (conn. side): Blue: 3
(+) Accessory/Starter Relay Input: Red/Black: 2
(+) Ignition 2/Flex Relay Output: Pink/White: 4
(+) Starter Output (to starter): Violet: 7
(+) Ignition 2/Flex Relay Input: Red/White: 9
(+) Ignition Input/Ouput: Pink: 10
18
36
HS CAN Low: Tan: 1
HS CAN High: Tan/Black: 2
FT CAN Low: Orange/Brown: 3
FT CAN High: Orange/Green: 4
Immo. Data: Orange/Black: 7
(-) PTS Output: Lt. Green/Black: 1
(+) Siren Output: Brown/Red: 11
(-) Hood Input: Gray: 21
DS4+
Proper Fuse
Positioning
(+) 12V Input: Red: 6 & 12
(-) Ground: Black: 10
(+) 12V Input: Red: 5
Starter Input (Key Side): Green: 6
(+) Accessory Output: Orange: 8
to open
It is important to check that the
fuses are positioned correctly.
).
DS4
DS4
Slide
DS4+
DS4+ HONDA56
