Directed DS4+ Installation Manual page 11

Wire Information
Function
Acura ZDX 2010-2012
12V
Starter
Ignition
Accessory
Immobilizer Data
Immobilizer Ignition Interrupt
B-CAN High
B-CAN Low
Parking Lights
F-CAN High
F-CAN Low
Honda Accord 2008-2012
12V
Starter
Ignition
Accessory
Immobilizer Data
Immobilizer Ignition Interrupt
B-CAN High
B-CAN Low
Parking Lights
F-CAN High
F-CAN Low
Honda Accord Crosstour 2010-2012
12V
Starter
Ignition
Accessory
Immobilizer Data
Immobilizer Ignition Interrupt
B-CAN High
B-CAN Low
Parking Lights
F-CAN High
F-CAN Low
Honda Odyssey 2011-2017
12V
Starter
Ignition
Accessory
Immobilizer Data
Immobilizer Ignition Interrupt
B-CAN High
B-CAN Low
Parking Lights
F-CAN High
F-CAN Low
11
Color Pin Polarity
White 1 (+)
Yellow 2 (+)
Blue 3 (+)
Green 5 (+)
Lt. Green 2 Data
Yellow 6 Cut
Pink 4 Data
Blue 5 Data
Gray 11 (-)
White 6 Data
Red or Black 14 Data
White 1 (+)
Yellow 2 (+)
Blue 3 (+)
Orange 5 (+)
Lt. Green 2 Data
Yellow 6 Cut
Pink 4 Data
Blue 5 Data
Gray 11 (-)
White 6 Data
Red or Black 14 Data
White 1 (+)
Yellow 2 (+)
Blue 3 (+)
Orange 5 (+)
Lt. Green 2 Data
Yellow 6 Cut
Pink 4 Data
Blue 5 Data
Gray 11 (-)
White 6 Data
Red or Black 14 Data
White 1 (+)
Yellow 2 (+)
Blue 3 (+)
Orange 5 (+)
Violet 2 Data
Yellow 6 Cut
Pink 4 Data
Blue 5 Data
Gray 11 (-)
White 6 Data
Black 14 Data
Connector Information
Location
Ignition switch.
Ignition switch.
Ignition switch.
Ignition switch.
Immobilizer control unit around ignition cylinder.
Immobilizer control unit around ignition cylinder.
Immobilizer control unit around ignition cylinder.
Immobilizer control unit around ignition cylinder.
Headlight switch.
OBDII.
OBDII.
Ignition switch.
Ignition switch.
Ignition switch.
Ignition switch.
Immobilizer control unit around ignition cylinder.
Immobilizer control unit around ignition cylinder.
Immobilizer control unit around ignition cylinder.
Immobilizer control unit around ignition cylinder.
Headlight switch.
OBDII.
OBDII.
Ignition switch.
Ignition switch.
Ignition switch.
Ignition switch.
Immobilizer control unit around ignition cylinder.
Immobilizer control unit around ignition cylinder.
Immobilizer control unit around ignition cylinder.
Immobilizer control unit around ignition cylinder.
Headlight switch.
OBDII.
OBDII.
Ignition switch.
Ignition switch.
Ignition switch.
Ignition switch.
Immobilizer control unit around ignition cylinder.
Immobilizer control unit around ignition cylinder.
Immobilizer control unit around ignition cylinder.
Immobilizer control unit around ignition cylinder.
Headlight switch.
OBDII.
OBDII.
Color Pins Ref.
White 5 A
White 5 A
White 5 A
White 5 A
White 7 B
White 7 B
White 7 B
White 7 B
Black & White 12 C
Black 16 D
Black 16 D
White 5 A
White 5 A
White 5 A
White 5 A
White 7 B
White 7 B
White 7 B
White 7 B
Black & White 12 C
Black 16 D
Black 16 D
White 5 A
White 5 A
White 5 A
White 5 A
Black 7 B
Black 7 B
Black 7 B
Black 7 B
Black & White 12 C
Black 16 D
Black 16 D
White 5 A
White 5 A
White 5 A
White 5 A
White 7 B
White 7 B
White 7 B
White 7 B
Black & White 12 C
Gray or White 16 D
Gray or White 16 D
