Operation

8 Operation
Device settings configured
Q

Switching on the device

8.1
Device connected to the mains elec-
Q
tricity or battery fully charged.
Press the On/Off key on the device.
Q
The device will perform a self-test:
Note: Pay attention to audible and visible
alarms, the lighting up of the two status
LEDs and the display during the self-test.
First the green and the yellow LEDs light up,
and then the yellow LED changes colour
to red.
Note: The yellow LED only lights up if the
function has been enabled in the Service Tool.
Note: Alternatively, the device can be
switched on by opening the door.

Inserting the infusion line

8.2
Device switched on.
Q
Infusion line primed
Q
Open the pump door by pulling on the
Q
lever. To do this, grip the door lever
from behind and pull it forward.
CAUTION! Free-flow
Make sure that the roller clamp is
Q
closed before inserting the line.
Never leave the pump unattended
Q
while the line is being inserted.
Always insert the line completely
Q
and then close the door.
26
38932401_Infusomat_compactPlusP_EN_IFU_1020_v5.indd 26
Inserting the infusion line:
Q
Push the active safety clamp down.
–
When inserting the infusion line,
–
pay attention to orientation with
regard to the direction of flow
(see diagram), as otherwise there is
a risk of backflow.
Insert the line fully into the guide
–
and press it in.
Insert the infusion line into the air
–
sensor on the left and make sure
that the line fits tightly.
Push the infusion line on the right
–
into the passive safety clamp.
