Operation
Soft limits
Soft limits for rate/dose/bolus volume
and bolus rate can also be stored in the
database. These can be exceeded with
no restriction but the following message
appears on the display.
The following symbols that describe the
status of the pump with regard to the soft
limits are described:
Symbol Meaning
No symbol
Infusion is within the
soft limits
Infusion is above the
upper soft limit
Infusion is below the
lower soft limit

Calculating the dose

8.10
The Dose calculation function is used to
calculate the delivery rate in ml/h based on
the dose parameters entered.
Infusion line inserted and selected
Q
Press the Menu key.
Q
32
38932401_Infusomat_compactPlusP_EN_IFU_1020_v5.indd 32
The main menu is displayed.
Select Dose calculation and press OK
Q
to confirm.
Select active substance unit and
Q
press OK to confirm.
Enter active substance quantity and
Q
press OK to confirm.
Enter volume and press OK to con-
Q
firm.
The "Calculate Using:" screen is
displayed.
Calculating without patient data
The delivery rate is calculated without any
patient data being entered.
Select No patient data and press OK
Q
to confirm.
Select dose unit and press OK to
Q
confirm.
Enter dose.
Q
Note: Pressing the OK key brings up the
Overview screen.
Check the plausibility of the displayed
Q
values.
Start the infusion with the Start/Stop
Q
key.
