Alarms

9 Alarms

Device alarms

9.1
If a device alarm is triggered the infusion is
stopped immediately.
Press the On/Off key to switch off
Q
the device.
Switch the device on again.
Q
If there is another technical alarm:
Disconnect the patient.
Q
Remove the disposable article.
Q
Switch off the device and send it to
Q
the technical service.
Pre-alarms and
9.2
operating alarms
WARNING! Setting alarm thresholds
incorrectly may endanger the patient.
Ensure that the alarm limits are set
Q
so that the alarm can be triggered
in good time. This applies for maxi-
mum pressure in particular.
The operating alarms have a high priority.
Pre-alarms and reminder alarms have a
lower priority. If there are two pre-alarms
at the same time, the pre-alarm with the
shorter remaining time is displayed.
The time lag between the triggering of
the alarm and the activation of a staff
call is less than a second and is therefore
negligible.
The alarm pre-settings are retained in the
event of a power failure.
38932401_Infusomat_compactPlusP_EN_IFU_1020_v5.indd 35

Pre-alarms

9.2.1
In the event of a pre-alarm, an acoustic
signal sounds and a staff call is activated.
The display remains in pre-alarm until the
operating alarm goes off. Pre-alarms do not
cause delivery to be interrupted.
Display Meaning
notification
"Volumes
Preselected volume
Q
nearly
has almost been
infused"
infused
Remaining volume is
Q
displayed
"Infusion
Preselected time is almost
time nearly
over
reached"
"Battery
The battery is almost
nearly
discharged
empty"
"KVO runs
Volume/time have been
for another
reached and the pump
xx min:sec"
continues with KVO rate.
A pre-alarm can be muted for 2 minutes by
pressing the OK key. The following symbol is
shown in the display:
Note: In the Service Tool, there is also the
option to display an additional prompt, which
enables a permanent mute until the end of
treatment alarm. The following symbol is
shown in the display:
35
