B. Braun Infusomat Space Quick Reference

Infusomat
®
Infusion Pump System
2 Generation Software
ND
Quick Reference
NAVIGATION
Programming through screens:
The pump screens will always indicate what
keys to press.
Entering values:
Use the left and right arrow keys
the cursor so the desired numerical value is
highlighted.
Use the up and down arrow keys to increase or
decrease the number.
Accessing Home Screen:
Pump returns to the Home screen when stopped.
Press while infusion is running to return to
the Home screen. Access all menus from the
Home screen.
Home
Symbol
Scroll Bar appears on screens when more
NOTE:
information is available.
CHANGE PUMP DISPLAY
With the pump running, press
preferred value to display on bottom left corner
of display, (i.e. drug long name, Care Unit, volume
totals, etc.)
Space
®
to move
Scroll Bar
or to choose
OPEN DOOR AND LOAD IV LINE
1. Press to power on.
2. Press door open key
and press to open door.
Keep the roller clamp closed while
CAUTION:
inserting IV line.
3. (1) Load IV line from right to left.
Insert the two hole clip.
(2) Attach white pronged clip.
Ensure silicone tubing segment is not
NOTE:
twisted.
(3) Insert the green anti-free flow clip in the
green slot (with hook facing down and away
from pump) until the opening lever snaps
out and the flashing yellow light goes out
indicating pump has occluded IV line.
4. Press IV line into the air sensor guide and
notches on right and left side of the pump.
5. Close the pump door by firmly placing pressure
until you feel the pump pull the door shut.
Do not open the roller clamp until pro-
NOTE:
gramming prompt appears.
Pump door will not close and pump
CAUTION:
alarms if the anti-free flow clip is not properly
inserted. Do not force door closed, check IV line
and anti-free flow clip (green) for proper loading.
6. If priming is activated, press
on the pump.
7. Note prompt to "Disconnect IV line from
patient before priming," press
8. Respond to "Priming stopped" message by
confirming with
prompt with
1
. Respond to prompt
to prime
to confirm.
. Respond to "Repeat priming"
for "Yes" or for "No."
