III. ASSEMBLY INSTRUCTIONS
Assembly the outer frame as pictured then place the lifting board pieces on top.
36
35
2
4
35
36
35
28
37
35
3 48 36
5
STEP 1
1. Attach the connection frame (2) to right bottom framework and right bottom connection
frame (4) and left bottom connection frame (5), using screw rod (28), screw M10X85 (37),
flat washer Ф10 (35) and lock nut M10 (36).
2. Attach the connection frame (2) to the foot rack (3), using screw M10X75 (48), flat washer Ф10 (35)
and lock nut M10 (36).
