Download the latest documents from edwardsvacuum.com/HSForms/, follow the
procedure in HS1, fill in the electronic HS2 form, print it, sign it, and return the signed
copy to us.
NOTICE:
If we do not receive a completed HS2 form, your equipment cannot be serviced.

9.3 Spares

See Table: Spares and maintenance kits
the RV pumps.
As of the end of 2009 improved motors have been fitted to RV pumps. These motors
benefit from being fitted with an aluminium terminal box and externally accessible
voltage change over switches. The introduction of these motors has resulted in the
range of motors covering all voltage and frequency conditions being reduced from four
variants to two. All motors are interchangeable and pump performance is not affected.
Table 17 Spares and maintenance kits
Spare
Ultragrade 19 oil, 1 litre
Ultragrade 19 oil, 4 litres
Fomblin 06/6 oil, 1 kg
Fomblin 06/6 oil, 5 kg
Clean and overhaul kit (Standard)
RV3 Blade kit
RV5 Blade kit
RV8 Blade kit
RV12 Blade kit
RV3 Cartridge kit
RV5 Cartridge kit
RV8 Cartridge kit
RV12 Cartridge kit
Inlet-valve kit
Coupling Element RV Pump Japan kit
Motor starting relay kit*
Motor starting relay kit (Europe/USA)**
Motor starting relay kit (Japan)**
Outer shaft seal kit
Rotor sleeve kit
Motor kit (Europe/USA) 50/60 Hz,
450/500 W, 1 phase, 110-120/220-240 V
A65201880_AA
A65201880_AA - Service and spares
for the spares and maintenance kits available for
Hydrocarbon prepared pumps
H110-25–015
H110-25-013
A652-01-131
A652-01-130
A653-01-130
A654-01-130
A655-01-130
A652-01-032
A653-01-032
A654-01-032
A655-01-032
A652-01-036
A210-71-778
A505-74-000
A071-08-732
A071-08-733
A652-01-134
A652-01-136
A652-99-500
Page 51
Item Numbers
PFPE prepared pumps
- H113-06-019
- H113-06-020
A652-01-131
A652-01-130
A653-01-130
A654-01-130
A655-01-130
A652-09-032
A653-09-032
A654-09-032
A655-09-032
A652-01-036
A210-71-778
A505-74-000
A071-08-732
A071-08-733
A652-01-134
A652-09-136
A652-99-500
03/2021 - ©Edwards Limited
-
-
