Figure 10 Accessories

1. Inlet catchpot 1. Inlet catchpot
3. Inlet desiccant trap 3. Inlet desiccant trap
5. Solenoid operated gas-ballast valve 5. Solenoid operated gas-ballast valve
7. Solenoid operated pipeline valve 7. Solenoid operated pipeline valve
9. Gas-ballast adaptor 9. Gas-ballast adaptor
11. Vibration isolators 11. Vibration isolators
A65201880_AA
A65201880_AA - Service and spares
1
5
9
11
2 3
6 7
10
12
2. Inlet dust filter 2. Inlet dust filter
4. Inlet chemical trap 4. Inlet chemical trap
6. Foreline trap 6. Foreline trap
8. Outlet mist filter 8. Outlet mist filter
10. Gravity oil drain kit 10. Gravity oil drain kit
12. Oil drain-extension 12. Oil drain-extension
