Figure 9 Sight-glass assembly

1. Screws (2 off M6 x 20) 1. Screws (2 off M6 x 20)
3. Sight-glass 3. Sight-glass
5. Oil-box 5. Oil-box

6.8 Clean the motor fan-cover and enclosure

If the motor fan-cover and enclosure are not kept clean, the air-flow over the motor can
be restricted and the pump may overheat.
1. Switch off the pump and disconnect it from the electrical supply.
2. Use a dry cloth and a soft brush to remove dirt and deposits from the fan-cover
and enclosure.

6.9 Clean and overhaul the pump

Clean and overhaul the pump as described in the instructions supplied with the clean
and overhaul kit (see

6.10 Fit new blades

Fit new blades to the pump as described in the instructions supplied with the blade kit
(see Spares
A65201880_AA
A65201880_AA - Maintenance
5
Spares on page 51).
on page 51).
Page 45
4
3
2
2. Bezel 2. Bezel
4. O-ring 4. O-ring
