12. Dimensions

Model
No.
P A
AMK20 1/8・1/4 40
AMK30 1/4・3/8 53
AMK40 1/4・3/8・1/2 70
semi-standard bowl
Semi-standard
specifications
Model
Metal bowl
No.
B
AMK20 139.1
AMK30 167
AMK40 212.6
(Port size)
2xP
Standard specifications
B C D E
133.9 17.5 21 -
167 21.5 26.5 30
212.7 25.5 35.5 38.4
G J M N
25 21 30 27
35 26.5 41 35
40 35.5 50 52
-24-
(Port size)
2xP
Bracket mount
Q R S T
22 5.4 8.4 60
25 6.5 13 71
30 8.5 12.5 88
U V
2.3 28
2.3 32
2.3 39
