9. How to Replace the Components
Warning
Before replacement, make sure that no pressure remains in the equipment.
After replacement, confirm that the product satisfies specific functions and no external leakage occurs before
operating it.
1.1) Element disassembly [AMK20]
Step 1
Remove the joint from the product.
If the joint is tightened too much to be removed, use a
hook spanner until it can be loosened by hand.
Body
Joint
Step 2
Remove the element assembly by the holding part of
the element assembly (shown by the arrows below).
Holds the elements
Rotation
-16-
Pull upward
Element assembly
