4.1) Bowl disassembly [AMK30, AMK40]
Step 1
To remove the bowl assembly from the product, rotate for approx. 30 degrees while the lock button is held down.
Align the mating mark of the joint and bowl assembly and pull the bowl assembly down to remove it.
Body
Joint
Bowl Assembly
[Step 2]
Lock button
[Step 1]
Pull downward
-21-
Align the mating mark
Mating mark of the joint
Mating mark of the
bowl assembly
Rotate for 30
degrees
