- Page 1 Doc. No. AMX-OMZ0092 PRODUCT NAME Line Filter MODEL / Series / Product Number AFF50-(F,N)06 ~ (F,N)10(B,C,D)(-J,L,R,W,Z)-D AFF60-(F,N)10(B,C,D)(-J,L,R,W,Z)-D...
-
Page 2: Table Of Contents
Contents Page 1. Safety Instructions 2 to 6 2. Application 3. Standard specifications 4. How to Order 5. Construction / Options / Replacement parts 6. Bowl assembly specifications 10 to 11 6-1. Bowl assembly for AFF50 6-2. Bowl assembly for AFF60 7. -
Page 3: Safety Instructions
Line Filter Safety Instructions These safety instructions are intended to prevent hazardous situations and/or equipment damage. These instructions indicate the level of potential hazard with the labels of “Caution,” “Warning” or “Danger.” They are all important notes for safety and must be followed in addition to International Standards (ISO/IEC) , and other safety regulations. - Page 4 Line Filter Safety Instructions Caution The product is provided for use in manufacturing industries. The product herein described is basically provided for peaceful use in manufacturing industries. If considering using the product in other industries, consult SMC beforehand and exchange specifications or a contract if necessary.
- Page 5 Precautions for Design Warning 1) Carefully consider the application, required specifications, and operating conditions (pressure, flow rate, temperature, environment and power supply) in accordance with the latest catalog (SMC website), making sure not to exceed the specification range. 2) Consult SMC if no leakage is allowed due to the environment, or if the operating fluid is not air. 3) This product cannot be used in the following environments.
- Page 6 Installation Warning 1) Do not drop or apply impact during transportation or installation. It will cause damage to the product and result in operation failure. 2) Do not install in areas of high humidity or high temperature. Operation outside of the product specification range may cause damage to the product or operation failure, or shorten the product life.
- Page 7 Air Source Warning 1) Use clean air. Do not use compressed air containing chemicals, organic solvent, synthetic oil or corrosive gas as it may be cause of breakage of components or operation failure. 2) Air containing too much moisture may deteriorate the performance. Install the refrigerated air dryer or aftercooler before the line filter.
-
Page 8: Application
2. Application This product aims at eliminating excess saturated water and solid foreign matter in the air line. 3. Standard specifications Model No. AFF50 AFF60 Port size 3/4，1 Fluid Ambient and operating fluid temperature -5 to 60 C (No freezing) Proof pressure 1.5MPa Max. -
Page 9: How To Order
4. How to Order ❶ ❷ ❸ ❹ ❺ ❶ Symbol Description Body size ● ● ❷ ● ● Thread type ● ● ● ― ❸ Port size ● ● ● ● Without mounting option Mounting ● ● With bracket ●... -
Page 10: Construction / Options / Replacement Parts
5. Construction / Options / Replacement parts Construction / Options / Replacement parts AFF50 / AFF60 Replacement parts Part No. Parts description AFF50 AFF60 ① Element AFF54P-060AS AFF64P-060AS ② Bowl seal AM54P-160S Bowl assembly Refer to [6. Bowl assembly specifications] ③... -
Page 11: Bowl Assembly Specifications
6. Bowl assembly specifications 6-1. Bowl assembly for AFF50 － － Option symbol Semi-standard － symbol Semi-standard: "-" Semi-standard: "J" (Standard) Port thread Port thread ③Part No. ③Part No. type type AM54P-120AS-J AM54P-F120AS-J AM54P-120AS AM54P-N120AS-J Appearance Part No. Note1) － Option symbol Semi-standard －... -
Page 12: Bowl Assembly For Aff60
6-2. Bowl assembly for AFF60 － － Option symbol Semi-standard － symbol Semi-standard: "-" Semi-standard: "J" (Standard) Port thread Port thread ③Part No. ③Part No. type type AM64P-120AS-J AM64P-F120AS-J AM64P-120AS AM64P-N120AS-J Appearance Part No. Note1) － Option symbol Semi-standard － symbol Semi-standard: "W"... -
Page 13: Assembly Of Optional Parts
7. Assembly of Optional parts Bracket Mounting of bracket A Insert bracket A from the front side of the product so that the finger of the bracket A engages with the groove and the bottom of the body. (see drawing on the left) Groove Product Bottom... -
Page 14: Operation And Adjustment
8. Operation and Adjustment 8-1. Discharge from the product with drain cock ・ Pressurize the inside of the line filter when discharging drain. Drain will not be discharged properly if not pressurized. AFF50 / AFF60: Drain cock / With barb fitting (push type) ... -
Page 15: Manual Drain Discharge From The Auto Drain
8-2. Manual drain discharge from the auto drain ・ Pressurize the inside of the line filter when discharging drain. Drain will not be discharged properly if not pressurized. ・ To discharge the auto drain manually, follow the procedure below. After discharging the drain, rotate the cock to the opposite direction by hand to close the drain valve. -
Page 16: Troubleshooting
9. Troubleshooting Refer to [10. How to Replace the Components](P16 and 17) and [11. Disassembly Drawing](P18). Problem Page for Possible causes Countermeasure reference Category Failure As pressure drop 1. Clog of the element. Replace the element. is large, fluid does not flow. P16 and Air leaks 1. -
Page 17: How To Replace The Components
10. How to Replace the Components ！ Warning Before replacement, make sure that no pressure remains in the equipment. After replacement, confirm that the product satisfies specific functions and no external leakage occurs before operating it. 10-1. Bowl assembly Replacement Work Model Work step... -
Page 18: Element Replacement
10-2. Element Replacement Work Model Work step classifi Tools Criteria cation 1) Remove the bowl assembly by referring to the section [10- 1. Bowl assembly Replacement] (P16). AFF50 AFF60 － － 2) Install the replacing element and bowl seal in the bowl assembly. -
Page 19: Disassembly Drawing
11. Disassembly Drawing AFF50 / AFF60 Mounting screws (4 pieces) Body ② Bowl seal ① Element ③ Bowl assembly -18-... -
Page 20: Dimensions
12. Dimensions (Port size) Semi-standard: With element service indicator Indicator Option specifications With Standard specifications Model Bracket mount auto drain 3/4 ・ 1 AFF50 237.7 40.5 52.5 259.2 AFF60 314.8 40.5 52.5 336.3 Semi-standard specifications SUS bowl Model With With indicator Barb fitting drain guide... - Page 21 Revision history 4-14-1, Sotokanda, Chiyoda-ku, Tokyo 101-0021 JAPAN Tel: + 81 3 5207 8249 Fax: +81 3 5298 5362 https://www.smcworld.com Note: Specifications are subject to change without prior notice and any obligation on the part of the manufacturer. © 2022 SMC Corporation All Rights Reserved...
