3) AMK40 bowl assembly
Semi-standard
symbol
Semi-standard symbol: "-"
（Standard）
Port
thread
type
Rc
G
NPT
Appearance and
part No.
Semi-standard symbol: "6"
Port
thread
type
Rc
G
NPT
Semi-standard
symbol
Semi-standard symbol: "2"
Port
thread
type
Rc
Appearance and
G
part No.
NPT
Note 1) Part No. ④ includes Bowl seal ③. Refer to [11. Disassembly Drawing ](P23).
Note 2) "Z" in Part No. ④ indicates standard specifications. The pressure unit: psi. The temperature unit:
Note 3) Refer to [4. How to Order] (P9) for option and semi-standard symbols
-
④ Part No.
C4SK-D
C4SK(-Z)-D
④ Part No.
C4SK-6-D
C4SK-6(Z)-D
2
④ Part No.
C4SF-2-A-X401
C4SF-2(Z)-A-X401
6
