12. Dimensions

Model
P
AFG20-D 1/8, 1/4
AFG30-D 1/4, 3/8
AFG40-D 1/4, 3/8, 1/2
AFG40-06-D 3/4
PC/PA bowl
Model
With
barb
fitting
B
AFG20-D -
AFG30-D 123.9
AFG40-D 155.6
AFG40-06-D 157.6
Standard specifications
A B C D
40 87.6 17.5 21
53 115.4 21.5 26.5
70 147.1 25.5 35.5 38.4
75 149.1 27 35.5 38.4
Semi-standard specifications
Metal bowl
With With With
drain drain drain
guide cock guide
B B B
91.4 87.4 93.9
122.2 117.8 122.3
153.9 149.5 154
155.9 151.5 156
E G J M N
- 25 21 30 27
30 35 26.5 41 35
40 35.5 50 52
40 35.5 50 52
Metal bowl with
level gauge
With With
drain drain
cock guide
B B
- -
137.8 142.3
169.5 174
171.5 176
27
Optional specifications
Bracket mount
Q R S T U
22 5.4 8.4 60 2.3
25 6.5 13 71 2.3
30 8.5 12.5 88 2.3
34 8.5 12.5 88 2.3
With
auto
drain
V B
28 104.9
32 157.1
39 186.9
43 188.9
