Para protect Para protect
Enable SW Enable SW
Unit name Unit name
W-AREA1 W-AREA1
W-AREA2 W-AREA2
ORG
Link Offset
Correct
Sensor type Sensor type
Option 1 Option 1
Undefine Undefine
No. 11 No. 11
Undefine Undefine
No. 12 No. 12
∗1 The range varies depending on the actuator. Please refer to the manual of the actuator for more
details.
Sets the range in which parameter and step data can be
changed.
1. Basic parameter + Step data (Basic parameter + Return to
1 to 2
origin parameter + Step data)
2. Basic parameter (Basic parameter + Return to origin
parameter)
This defines the status of the Enable switch of the teaching
box.
1 to 2
1. Enabled
2. Disabled
Indication of actuator type compatible with the controller.
Fixed value
(Do not change the setting)
This is the setting to define the conditions where the
Basic parameter
"W-AREA" signal will turn ON. [Unit: mm]
"Stroke (-)" -
If the current position is within the range between the
"Stroke (+)"
W-AREA1 and W-AREA2, "WAREA" will turn ON.
∗ If W-AREA1 >W-AREA2, the "Parameter ALM" alarm will be
Basic parameter
"Stroke (-)" -
activated. However if W-AREA1= W-AREA2 = 0, "WAREA"
"Stroke (+)"
will be OFF and no alarm will be generated.
This is the fixed value for this controller.
Fixed value
(∗ Do not change the setting)
This is the fixed value for this controller.
Fixed value
(∗ Do not change the setting)
This is the fixed value for this controller.
Fixed value
(∗ Do not change the setting)
This is the fixed value for this controller.
Fixed value
(∗ Do not change the setting)
This is the fixed value for this controller.
Fixed value
(∗ Do not change the setting)
