The USB
driver is
not
installed
Incorrect
COM port
setting
Communication
fault
6
(JXC－W2A-C)
Connection
failure
Lock
release
error
External
equipment
failure
Does not
7
operate at all.
Unsuitable
spec.
Stop
command
Check that the USB driver for
the conversion unit is installed.
Please confirm if the correct
COM port is set to the ACT
Controller.
Please confirm the connection
status.
When the unlock switch is turned
ON or OFF there is an unlocking
sound made.
Check that the PLC connected to
the controller operates correctly.
Test operation of the controller
on its own.
Check if the controller's
specifications are appropriate,
the power supply is suitable and
the controller is compatible with
the actuator.
If it is not energized, the servo
will be OFF and does not
operate. Check if a voltage of 24
VDC is applied to the EMG
terminal.
-78-
Please install the USB driver of the
communication unit.
The USB driver's installation starts when
the communication unit is connected
with PC. Details of the installation
procedure are shown in "Installation
procedure of the JXC-W2 setting
software".
The COM port allocated to the controller
is different for different PC's. Check and
confirm the COM port number with the
controller connected to the PC.
The COM port number can be checked
using the Device Manager of the PC.
For details of the COM port checking
and setting methods refer to the
"JXC-W2 Controller Configuration
Software Installation Manual".
Please confirm motor controller (JXC) =
communications cable = communication
unit = USB cable = PC is connected. For
example, communication cannot be
established if the connector has been
damaged.
Please confirm the power supply of
motor controller (JXC) has been turned
ON. Communication cannot be
established if the power supply is OFF.
If equipment other than the motor
controller (JXC) (PLC and measurement
equipment) is connected with PC,
remove these before checking. (There is
a possibility that the communication with
other equipment interferes in PC.)
If there is no sound of lock release, the
lock brake may be broken.
→ If the problem persists, please
contact SMC.
Refer to the controller operation manual
and take appropriate measures.
→ 9.1 Memory allocation (P.29)
Take appropriate measures according
to this manual.
→ 3. Specifications (P.13)
Apply 24 VDC to the EMG terminal.
