15.2 Alarms and countermeasures

Controller
setting Teaching
Group
software box
(code) ∗1
Drive data
Step
value is
data
wrong
ALM1
(01-048)
Parameter
Parame
value is
ter
wrong
ALM
(01-049)
Set step
data is not Step
registered data
on list. ALM2
(01-051)
Set stroke
is outside
Stroke
the stroke
limit
limit.
(01-052)
How to
deactivate
<Condition>The step data is incorrect for the following conditions
(Settable range)
(1) Area1 <Area2
(If both Area1 and Area2 is 0, the alarm will not be activated.)
(2) Trigger LV ≤ Pushing force
(3) Minimum speed of actuator ≤ Pushing speed ≤ Speed
(4) Pushing speed ≤ Maximum pushing speed of actuator
(5) Pushing force ≤ Minimum pushing force of actuator
B RESET
(6) Basic parameter "Maximum pushing force" ≥Minimum pushing force of
the actuator
(7) Basic parameters "Max pushing force" ≥ Threshold
<Countermeasure> Modify the step data and basic parameters setting
Please refer to the manual or the catalogue of the actuator for the
max/min pushing force/speed for the actuator.
<Contents> The basic parameter is not correct for the following condition:
(Settable range)
(1) Stroke(-) < Stroke (+)
(2) W-Area 1 < W-Area 2
(∗ If both W-Area1 and W-Area2 is 0, the alarm will not be activated.)
B RESET
(3) Maximum pushing force < Maximum pushing force of actuator
<Countermeasure> Modify the basic parameter setting.
Please refer to the manual or the catalogue of the actuator for the
maximum pushing force for the actuator.
<Contents> For an operation for a specific step data no., the requested
number of the step data is not registered. (When operation is commanded
through PLC, this alarm will be generated depending on the signal interval
and the holding time of signals)
< Countermeasure >
(1) Make sure that the "Movement MOD" in the step data is not "Blank
B RESET
(Disabled)" and that numbers [1(ABS)] and [2(INC)] or input in the
numerical instruction operation.
(2) Set the interval time between signals to more than twice the
communication cycle time, when signals are to be continuously input,
because PLC processing delays and controller scanning delays can
occur.
Refer to 13.2[2] Positioning operation (P.50)
<Contents> The actuator goes outside the stroke limit specified by the
basic parameters, "Stroke (+)" and "Stroke (-)" if it performs the requested
operation. (Including JOG operation after return to origin)
<Countermeasure> Make sure that the basic parameters, "Stroke (+)" and
"Stroke (-)" are consistent with the distance of actuator movement
specified in the step data.
B RESET
If the operation method of step data is "relative coordinated
movement", note the location where the operation starts and the
distance traveled. If the location is out of the stroke range when the
power is supplied, this alarm is generated. Move the table within
stroke range, and supply power.
Alarm contents/Countermeasure
Caution
Caution
Caution
