Access Power Controller Terminal Identification:

Terminal Legend
– Power +
– Control +
TRIGGER INPUT1 -
INPUT 8 IN, GND
OUTPUT 1-
OUTPUT 8
NC, C, NO, COM
FACP INTERFACE
T, + INPUT –
FACP INTERFACE
NC, C, NO

Power Supply Board Stand-by Battery Specifications:

Battery Maximal3FD
7AH
12AH 30 Mins./6A*
40AH Over 4 Hours/6A*
65AH Over 4 Hours/6A*
*Only these configurations can be utilized in ULC-S319 installations.
- 8 -
Function/Description
12VDC or 24VDC from power supply/charger (factory connected).
These terminals are paralleled to the [– Control +] terminals.
These terminals are paralleled to the [– Power +] terminals.
These terminals can be connected to an external Listed power-limited access control
power supply to provide isolated operating power for the devices (Not evaluated by UL).
Jumpers J1 and J2 must be removed.
From normally open and/or open collector sink trigger inputs
(request to exit buttons, exit PIRs, etc.)
12VDC to 24VDC trigger controlled outputs are rated at 2.5A.
Maximal3FD - 9.7-13.2VDC @ 4.6A or 19.8-26.4VDC @ 5.2A.
Maximal5FD - 9.7-13.2VDC @ 8.6A.
Maximal7FD - 19.8-26.4VDC @ 9.2A.
Fail-Safe [NC positive (+) and COM Negative (–)], Fail-Secure [NO positive (+) and
COM Negative (–)], Auxiliary output [C positive (+) and COM Negative (–)].
When using AC power supplies polarity needs not to be observed.
Contacts shown in a non-triggered state.
Fire Alarm Interface trigger input from FACP. Trigger inputs can be normally open,
normally closed from an FACP signaling circuit output (Figs. 5-9, pg. 12).
Form "C" relay contact rated @ 1A 28VDC for alarm reporting (not evaluated by UL).
10 Mins./6A
Maximal5FD
5 Mins./10A
30 Mins./10A*
Over 2 Hours/10A*
Over 4 Hours/10A*
Maximal3FD/Maximal5FD/Maximal7FD Access Power Controllers (PTC)
Maximal7FD
5 Mins./10A
30 Mins./10A*
Over 2 Hours/10A*
Over 4 Hours/10A*
