Access Power Controller Led Diagnostics; Power Supply Board Terminal Identification; Access Power Controller Terminal Identification - Altronix Maximal Series Installation Manual

Red (Bat) Battery Status
ON Normal operating condition.
OFF Battery fail/low battery.
LED
LED 1- LED 8 (Red)
Trg (Green)
Terminal
Function/Description
Legend
L, N Connect 115VAC 60Hz to these terminals: L to hot, N to neutral.
Maximal3D - 12VDC @ 5 amp or 24VDC @ 5.4 amp to ACM8CB boards (power-limited)
+ DC - Maximal5D - 12VDC @ 9 amp to ACM8CB boards (power-limited).
Maximal7D - 24VDC @ 9.4 amp to ACM8CB boards (power-limited).
Indicates loss of AC power. To meet with UL requirements it is mandatory to connect visual notification
AC FAIL
devices, connecting audible notification devices is optional. Relay normally energized when AC power is
NC, C, NO
present. Contact rating 1 amp @ 28VDC. AC or brownout fail is reported within 1 minute of event.
Indicates low battery condition, e.g. connect to access control panel. Relay normally energized when
DC power is present. Contact rating 1 amp @ 28VDC. A removed battery is reported within 5
BAT FAIL
minutes. Battery reconnection is reported within 1 minute. Low battery threshold:
NC, C, NO
12VDC output threshold set @ approximately 10.5VDC.
24VDC output threshold set @ approximately 21VDC.
Stand-by battery connections. Connect one (1) 12VDC battery to the terminals marked [+ BAT -]
+ BAT - for 12VDC operation (Figs. 3 and 3a, pg. 9). Use two (2) 12VDC batteries wired in series for 24VDC
operation (Fig. 4, pg. 10).
Terminal Legend
- Control +
- Power +
TRIGGER
INPUT 1- INPUT 8
IN, GND
OUTPUT 1-
OUTPUT 8
NC, C, NO, COM
FACP INTERFACE
T, + INPUT --
FACP INTERFACE
NC, C, NO
- 6 -
Power Supply Board LED Diagnostics:

Access Power Controller LED Diagnostics:

ON
Output relay(s) energized.
FACP input triggered (alarm condition).

Power Supply Board Terminal Identification:

Access Power Controller Terminal Identification:

Function/Description
12VDC or 24VDC input from power supply board.
Not applicable
From normally open and/or open collector sink trigger inputs
(request to exit buttons, exit pir's, etc.).
12VDC to 24VDC trigger controlled outputs:
Fail-Safe [NC positive (+) & COM Negative (-)], Fail-Secure [NO positive (+) &
COM Negative (-)], Auxiliary output [C positive (+) & COM Negative (-)]
(When using AC power supplies polarity need not be observed),
Contacts shown in a non-triggered state.
Fire Alarm Interface trigger input from FACP. Trigger inputs can be normally open,
normally closed from an FACP signaling circuit output (Figs. 8-12, pg. 14).
Form "C" relay contact rated @ 1 amp 28VDC for alarm reporting (not evaluated by UL).
OFF
Output relay(s) de-energized.
FACP normal (non-alarm condition).
Maximal3D/Maximal5D/Maximal7D Access Power Controllers (PTC)
