Terminal Legend
– Power +
– Control +
(only applicable for
Maximal11DV)
TRIGGER
INPUT 1-INPUT 8
IN, GND
OUTPUT 1-
OUTPUT 8
NC, C, NO, COM
FACP INTERFACE
T, + INPUT –
FACP INTERFACE
NC, C, NO
Altronix
Power Supply Board
Model
(Refer to Fig. 1a, pg. 7 for
Maximal11DV
location and position)
(Refer to Fig. 1a, pg. 7 for
Maximal33DV
location and position)
Maximal55DV
Maximal75DV (Factory set at 12VDC)
Maximal75DV
(Factory set at 24VDC)
Maximal77DV
(Factory set at 24VDC)
* Note: Additional battery enclosure required (Figs. 6-9, pg, 12-15).
- 6 -

Access Power Controller Terminal Identification:

Function/Description
12VDC or 24VDC input from power supply board.
These terminals can be connected to an external access control power supply to provide
isolated operating power for the ACM8CB (jumpers J1 and J2 must be removed). All field
wiring connections must be made employing suitable gauge CM or FPL jacketed wire
or equivalent substitute (Figs. 6a-9a, pgs. 12-15).
From normally open and/or open collector sink trigger inputs
(request to exit buttons, exit pir's, etc.)
12VDC to 24VDC trigger controlled outputs:
Fail-Safe [NC positive (+) & COM Negative (–)],
Fail-Secure [NO positive (+) & COM Negative (–)],
Auxiliary output [C positive (+) & COM Negative (–)]
(When using AC power supplies polarity needs not to be observed),
NC, C, NO convert to dry form "C" 5A/24VAC/VDC rated dry outputs when PTCs are removed.
Contacts shown in a non-triggered state.
Fire Alarm Interface trigger input from FACP. Trigger inputs can be normally open,
normally closed from an FACP signaling circuit output (Figs. 10-15, pg. 16).
Form "C" relay contact rated @ 1A 28VDC for alarm reporting.

Power Supply Board Stand-by Battery Specifications:

AL400XB2V
Switch [SW1]
AL600XB220
Switch [SW1]
AL1012XB220
AL1024XB2V
AL1024XB2V
20 Min. of
Battery
Backup
12VDC/40AH* N/A
24VDC/40AH* N/A
12VDC/40AH* N/A
24VDC/40AH* N/A
12VDC/12AH 9.0A
24VDC/12AH 7.7A
24VDC/65AH* N/A
Maximal11DV/Maximal33DV/Maximal55DV/Maximal77DV/Maximal75DV Access Power Controllers (PTC)
4 Hr. of Backup
3.5A
2.7A
5.5A
5.5A
Battery capacity for
emergency stand-by at
least 20 min
1.2A
7.7A
24 Hr. of Backup
0.5A
0.7A
5.5A
0.7A
N/A
N/A
1.2A
